Static tipping load with forks (straight):  3411 lb
Static tipping load with bucket (straight):  4828 lb
Max. height of bucket pivot point:   10 ft 4 in
Engine power (kW):  45.50 kW

  • Get a Quote Payment Calculator

    • Get information on the MLA 5-60 H-Z

    Fields with asterisks* are required. Please email our helpful staff with any questions or comments using the contact form.

    Loan Calculator

    Use the Loan Calculator to help you determine the financing and payment options that are best for you.

    Amount Financed ($)
    Interest Rate (%)
    Loan Term in Months
    Monthly Payment Calculated

    **The accuracy of this calculator and its applicability to your circumstances is not guaranteed. You should obtain personal advice from qualified professionals. This information is provided for illustrative purposes only and does not constitute an application. This notice does not guarantee loan approval, nor is it an offer or commitment to make a loan to you on the above terms.

MLA 5-60 H-Z Specs & Compare
Download PDF
Capacities
Static tipping load with bucket (straight)4828 lb
Static tipping load with bucket (full turn)3735 lb
Static tipping load with forks (straight)3411 lb
Static tipping load with forks (full turn)2654 lb
Max. height of bucket pivot point10 ft 4 in
Max. lifting height (below forks)9 ft 9 in
Reach at max. height1 ft 5 in
Breakout force with bucket4329.46 daN
Weight and dimensions
Unladen weight (with forks) with 4-post canopy7470 lb
Overall length to carriage (with hitch)13 ft 9 in
Wheelbase69 in
Overall width of 4 posts canopy4 ft
Overall cab width4 ft
Overall height with 4 posts canopy7 ft 7 in
Overall height with cab7 ft 7 in
Tilt-up angle39.90 °
Tilt-down angle44.70 °
Articulation angle45 °
Overall width less bucket4 ft 10 in
Ground clearance10 in
Performances
Crowd2.52 s
Dump1.85 s
Engine
Engine brandDeutz
Engine modelTD 2.2 L3
Engine normStage V / Tier 4 Final
Number of cylinders / Capacity of cylinders3 - 21 in³
Engine power (Hp / kW)60 Hp / 45.50 kW
Max. torque / Engine rotation148 ft/lbs / 2400 rpm
Engine cooling system2 radiators water + hydraulic oil
Transmission
Transmission typeHydrostatic
Number of gears (forward / reverse)2 / 2
Max. travel speed (may vary according to applicable regulations)18 mph
Differential lockFront and rear locking of the machine
Parking brakeManual
Service brakeHydraulic drum brake on front axle, acting on all 4 wheels
Hydraulics
Hydraulic pump typeGear pump
Hydraulic flow - Pressure15 US gpm / 3046 PSI
High-Flow Option (l/min)19 US gpm
Drive hydraulic system pressure6092 PSI
Tank capacities
Hydraulic oil12 US gal
Fuel tank22 US gal
Miscellaneous
Cab certificationROPS - FOPS cab (level 1)
MLA 5-60 H-Z Features & Benefits

The MLA 5-60 H-Z is the smallest of our lineup to have our Z-kinematic loaderarm, giving you unmatched break-out forces. The latest of our Articulated Loader lineup comes with an open canopy with additional options available in 2021. The 2-speed hydrostatic transmission, 100% diff lock and hand throttle is standard, making the MLA 5-55 have all the features you need for excellent performance and comfort. Small machine, big power.
