Rated Operating Capacity:  1951 lb
Overall Operating Height - Fully Raised:  158 in
Dump reach - Full height:  26 in
Overall length with bucket:  129 in

  • Get a Quote Payment Calculator

    • Get information on the 1950RT

    Fields with asterisks* are required. Please email our helpful staff with any questions or comments using the contact form.

    Loan Calculator

    Use the Loan Calculator to help you determine the financing and payment options that are best for you.

    Amount Financed ($)
    Interest Rate (%)
    Loan Term in Months
    Monthly Payment Calculated

    **The accuracy of this calculator and its applicability to your circumstances is not guaranteed. You should obtain personal advice from qualified professionals. This information is provided for illustrative purposes only and does not constitute an application. This notice does not guarantee loan approval, nor is it an offer or commitment to make a loan to you on the above terms.

1950RT Specs & Compare
Download PDF
Capacities
Operating Weight8150 lb
Unladen weight7544 lb
Operating Capacity At 50% Tipping Load2787 lb
Tipping capacity5571 lb
Weight and dimensions
Overall Operating Height - Fully Raised158 in
Height to Hinge Pin - Fully Raised120 in
Dump reach - Full height26 in
Dump angle at full height39 °
Overall length with bucket129 in
Departure angle27 °
Ground clearance7 in
Overall width less bucket69 in
Bucket Width70 in
Clearance Radius - Front with Bucket81 in
Engine
Engine brandYanmar
Engine model4TNV98C-NMS2V
Engine power (Hp)68.40 Hp
Engine power (kW)51 kW
Max. torque / Engine rotation178 ft/lbs @ 2500 rpm
Battery voltage12 V
Accessory plug120 V
Alternator - Ampere100 A
Transmission
Transmission typeHydrostatic
Hydraulics
Standard flow - Auxiliary hydraulics18 US gpm
Auxiliary Hydraulic Pressure3249 PSI
High-Flow Auxiliary Hydraulics - Option32 US gpm
High-Flow Auxiliary Hydraulics Pressure - Option2901 PSI
Tank capacities
Hydraulic tank capacity10 US gal
Fuel tank16 US gal
Liquid cooling tank volume3 US gal
Displacement / Number of cylinders0.87 US gal / 4
Noise and vibration
Noise to environment (LwA)101.40 dB
Noise at driving position (LpA)82 dB
Whole-Body Vibration (ISO 2631-1)4 ft/s²
