Technical characteristics | |
Manufacturer | Manitou |
Model Name | MI 35 G |
Power source | Lpg |
Operator type | Seated |
Max. capacity | 7716 lb |
Load center of gravity | 20 in |
Load distance, centre of drive axle to fork | 19 in |
Wheelbase | 67 in |
Weight | |
Service weight | 10450 lb |
Weight on front axle (laden) / rear axle (laden) | 16006 lb / 2161 lb |
Weight on front axle (Unladen) / rear axle (Unladen) | 3913 lb / 6537 lb |
Wheels | |
Tires type | Solid tires |
Dimensions of front wheels | 28-9-15 12 |
Dimensions of rear wheels | 6.50-10 10 |
Number of front wheels / rear wheels | 2 / 2 |
Number of drive wheels | 2 |
Front wheel gauge | 40 in |
Rear wheel gauge | 38 in |
Dimensions | |
Height of overhead guard (cabin) | 84 in |
Seat height/stand height | 48 in |
Height of towing bar (coupling height) | 14 in |
Overall length | 155 in |
Length to face of forks | 110 in |
Overall width | 48 in |
Overall width - Single wheels | 48 in |
Forks section / width / length | 2 in x 5 in x 45 in |
Fork carriage ISO 2328 (class/form) A/B | 3A |
Fork carriage width | 43 in |
Ground clearance below mast | 5 in |
Ground clearance at centre of wheelbase | 8 in |
Aisle Width for pallets 1000 x 1200 crossways | 165 in |
Aisle width for 800 x 1200 pallet lengthways | 173 in |
Turning radius | 99 in |
Internal turning radius (over tyres) | 6 in |
Performances | |
Travel speed (laden / unladen) | 11 mph-11 mph |
Lifting speed (laden / unladen) | 1 ft/s-2 ft/s |
Lowering speed (laden / unladen) | 2 ft/s-1 ft/s |
Drawbar pull (Laden / Unladen) | 1750 daN / 1100 daN |
Gradeability (laden / unladen) | 18 % / 20 % |
Service brake | Hydraulic |
Engine | |
Engine brand / model | GCT (ex-Nissan) / K25 |
I.C. Engine power rating | 46 kW |
Rated speed | 2400 rpm |
Number of cylinders / Capacity of cylinders | 4 - 152 in³ |
Miscellaneous | |
Working hydraulic pressure for attachments | 2321 PSI |
Oil flow rate for attachments | 19 US gpm |
Measured/guaranteed mean noise level at the ear of the operator | < 80 dB |
Sound level at the driver's ear according to DIN 12 053 | 80 dB |
The MI 35 G is an industrial forklift designed for both indoor and outdoor applications with a maximum load capacity of 3.5 tonnes. It comes equipped with a Nissan LPG engine, with a wide range of masts and tyres available to meet your exact needs.The streamlined and spacious driver's position provides the operator with a pleasant and safe working space, which can easily be accessed from both sides. The ergonomic controls were designed to make day-to-day operation easier on the driver, and visibility has been maximised with the openwork roof, increased space between mast, slim profile rear posts for enhanced safety.
