Cut up to 3″ diameter trees and clear brush faster with a 40″ cut and up to 35% faster blade speed than 36″ mini-ex cutters, all while keeping weight as low as 510 pounds.

  • Get a Quote Payment Calculator

    • Get information on the XB39

    Fields with asterisks* are required. Please email our helpful staff with any questions or comments using the contact form.

    Loan Calculator

    Use the Loan Calculator to help you determine the financing and payment options that are best for you.

    Amount Financed ($)
    Interest Rate (%)
    Loan Term in Months
    Monthly Payment Calculated

    **The accuracy of this calculator and its applicability to your circumstances is not guaranteed. You should obtain personal advice from qualified professionals. This information is provided for illustrative purposes only and does not constitute an application. This notice does not guarantee loan approval, nor is it an offer or commitment to make a loan to you on the above terms.

XB39 Specs & Compare
Download PDF
MODELXB39
Cut Width (Inches)40.1
Overall Width Without Sides / With Sides (Inches)52.5 / 53.1
Height: Overall / Deck (Inches)19.7 / 6.1
Overall Depth (Inches)45.1
Minimum Cut Height (Inches)2.3
Cutting Capacity, Diameter (Inches)3.0
Deck Thickness: Top/Side (Inches)3/16
Recommended Flow Rate (GPM)13-25
Max Operating Pressure (PSI)3500
Approximate Weight: No Sides / Both Sides (Pounds)510¹ / 590¹
[Optional] Carbide Teeth: Weight (Pounds) / Qty6 / 9
Approximate Operating Weight (Pounds)Cutter (510) + Hanger + Options²
Mini-Ex's Lowest Lift Capacity Over Side at Max ReachMust Exceed Cutter Operating Weight³
Recommended Mini-Excavator Weight (Pounds)6500-15000
XB39 Features & Benefits
  • NO CASE DRAIN REQUIRED. DIRECT DRIVE EATON® MOTOR WITH RELIEF VALVE PROTECTION
  • WEIGHT OPTIMIZED TO BE COMPATIBLE WITH 6500LB (3 TON) MINI EXCAVATORS
  • DECK DESIGNED TO LIMIT FLYING DEBRIS FOR SAFER OPERATION. ADD OPTIONAL SIDES FOR MAX DEBRIS CONTAINMENT
  • ROUNDED FLYWHEEL WITH 3 DOUBLE-SIDED BLADES BOUNCES OFF STUMPS. ADD OPTIONAL TEETH FOR A BETTER FINISH
  • STANDARD 90″ HOSES, COUPLERS, MOTOR GUARD & SPINDLE GUARD
  • BOLT-ON MOUNTING INTERFACE FOR QUICKLY CHANGING HANGER BRACKETS. VARIOUS HANGER BRACKETS AVAILABLE TO FIT MOST EXCAVATOR BRANDS
  • RETROFIT HYDRAULIC BRAKE KIT AVAILABLE TO REDUCE OPERATOR WAIT TIME BY STOPPING BLADE ROTATION IN LESS THAN 15 SECONDS
