Legendary performance meets new transmission technology for easier-to-control, smoother, and more stable sod cutting.
The Bobcat® SC24H sod cutter’s innovative, hydrostatic, variable-speed transmission lets you power through the cut while its heavy-duty, long-lasting, cast-iron gear case and hydraulic cooling system stand up to the toughest demands – season after season.
Engine | |
---|---|
Engine Model | Honda GX160 |
Engine Displacement | 9.9 m³ |
Horsepower | 4.8 hp |
Fuel Capacity | 0.82 gal |
Performance | |
Weight | 398 lb |
Dimensions | |
Length | 52.5 in |
Width | 25 in |
Height | 35.5 in |
Wheels | |
Front Tire(s) | (2) 8 in vulcanized knob tread cast iron drive wheels |
Rear Tire(s) | (1) 9 in x 3.5 in - 4 in caster wheel |
Blade | |
Blade Material | Heat-treated 10B38 boron steel |
Cutting Width | 24 in |
Max Cutting Depth | 2.5 in |
Max Blade Speed | 1,225 rpm |
Depth Adjustment | Locking lever releases to desired depth |
Drive | |
Drive System | A-section belt from engine to hydrostat that transfers power through enclosed lubricated gearcase; Wheels: gears and chain reduction to drive wheels; Blade: gears to blade eccentric shaft |
Transmission | Hydro-Gear #BDU-10S-127; 10cc pump |
Gearbox | 0.25" thick cast iron housing |
Hydraulic Oil Capacity | 2.1 qt |
Max Forward Speed | 4 mph |
Max Reverse Speed | 2 mph |
